Z4 G4 Workstation Best-Selling Performance Most Popular Workstation for Engineering Visualizationand Machine Learning
The Z4 is ahead of its time with more standard features than any other single processor HP workstation. With multiple configuration options, you can choose the perfect blend of components that meet your performance requirements.
Visualize your project anytime with the power to move seamlessly between 3D CAD,rendering and simulation applications. The Z4 can easily handle tasks that require high frequency processing, multiple cores and high-powered GPUs for an optimized design process.
Perfect for engineering, visualization and Machine Learning, HP's most popular workstation delivers disruptive performance for a wide spectrum of applications. With a choice of Intel Xeon or CoreX processors, and support for dual extreme graphics, you get all you need, nothing more.
- Overview
- Related Products
The Z4 is ahead of its time with more standard features than any other single processor HP workstation. With multiple configuration options, you can choose the perfect blend of components that meet your performance requirements.
Visualize your project anytime with the power to move seamlessly between 3D CAD,rendering and simulation applications. The Z4 can easily handle tasks that require high frequency processing, multiple cores and high-powered GPUs for an optimized design process.
Perfect for engineering, visualization and Machine Learning, HP's most popular workstation delivers disruptive performance for a wide spectrum of applications. With a choice of Intel Xeon or CoreX processors, and support for dual extreme graphics, you get all you need, nothing more.
Product parameter
| Processor | Intel Core X-series processor; Intel Xeon W processor |
| Expansion Slots | 1 PCIe 3 x16; 2 M.2 PCIe 3 x4 |
| Chipset | Intel C422; Intel X299 |
| Memory | Memory Slots: 8 DIMM 512 GB DDR4-2933 ECC SDRAM (for Intel Xeon configurations); 256 GB DDR4-2933 non-ECC SDRAM (for Intel Core X configurations); Transfer rates up to 2666 MT/s. |
| Internal storage | up to 300 GB SAS (15000 rpm)：500 GB up to 2 TB SATA (7200 rpm) up to 500 GB SATA SED (7200 rpm)：1 TB up to 8 TB 7200 rpm SATA Enterprise；256 GB up to 2 TB SATA SSD；256 GB up to 512 GB SATA SED Opal 2 SSD；240 GB up to 1920 GB SATA Enterprise SSD；256 GB up to 2 TB HP Z Turbo Drive PCIe NVMe SSD；256 GB up to 2 TB HP Z Turbo Drive PCIe NVMe SED SSD M.2；256 GB up to 8 TB HP Z Turbo Drive Quad Pro PCIe SSD；256 GB up to 4 TB HP Z Turbo Drive Dual Pro PCIe SSD |
| Graphics | Entry 3D: NVIDIA T400 (4 GB GDDR6 ); NVIDIA T400 (2 GB GDDR6 ) Mid-range 3D: NVIDIA RTX️ A2000 (12 GB GDDR6 ); NVIDIA T1000 (8 GB GDDR6 ); NVIDIA T1000E (8 GB GDDR6 ); AMD Radeon Pro W6600 (8 GB GDDR6 ); AMD Radeon Pro WX3200 (4 GB GDDR5 ); NVIDIA Quadro P1000 (4 GB GDDR5 ); AMD Radeon Pro WX 3100 Graphics (4 GB GDDR5 ); NVIDIA T1000 (4 GB GDDR6 ); NVIDIA RTX️ A2000 (6 GB GDDR6); NVIDIA RTX A2000 12GB High-end 3D: NVIDIA RTX️ A4000 (16 GB GDDR6 ); AMD Radeon Pro W6800 (32 GB GDDR6 ); NVIDIA RTX️ A4500 (20 GB GDDR6 ); AMD Radeon Pro W6600 (8 GB GDDR5 ) Ultra High-end 3D: NVIDIA Quadro SYNC II; NVIDIA RTX A5000 (24 GB GDDR6 ); NVIDIA RTX A6000 (48 GB GDDR6 ) |
| Power Supply | 1000 W ; 465 W ; 750 W |
| Dimensions (H x W x D) Weight |
15.2 x 6.65 x 17.5 in; 38.6 x 16.9 x 44.5 cm 22.4 lb; 10.2 kg |
