The ultimate in power and expandability- Z800 Workstation
Combining ultimate performance with a revolutionary new industrial design, the HP Z800 Workstation delivers the extreme speed and massive expandability that you demand to tackle your biggest challenges.
Designed for speed, inside and out, the new HP Z800 revolutionizes workstation industrial design. Featuring brushed aluminum side panels, integrated handles, visually cable-less engineering that maximizes airflow, modular component removal and reconnect, and optional liquid cooling (expected availability July 2009), among many other signature HP Workstation innovations, this is a system you’ll want everyone to see.
• Minimize power and cooling costs with ENERGY STAR qualified configurations featuring 85% or 88% efficient power supplies and an HP-developed energy-saving feature that helps lower energy consumption in off mode.
• See, share, and show your work across the world with built-in HP SkyRoom collaboration solution which combines real-time 3D graphics sharing and video conferencing
- Overview
- Related Products
Combining ultimate performance with a revolutionary new industrial design, the HP Z800 Workstation delivers the extreme speed and massive expandability that you demand to tackle your biggest challenges.
Designed for speed, inside and out, the new HP Z800 revolutionizes workstation industrial design. Featuring brushed aluminum side panels, integrated handles, visually cable-less engineering that maximizes airflow, modular component removal and reconnect, and optional liquid cooling (expected availability July 2009), among many other signature HP Workstation innovations, this is a system you’ll want everyone to see.
• Minimize power and cooling costs with ENERGY STAR qualified configurations featuring 85% or 88% efficient power supplies and an HP-developed energy-saving feature that helps lower energy consumption in off mode.
• See, share, and show your work across the world with built-in HP SkyRoom collaboration solution which combines real-time 3D graphics sharing and video conferencing
Product parameter
| Processor | Intel Xeon processors |
| Drive Bays | 3 external 5.25-inch bays, 4 internal 3.5-inch bays, Up to 4 eSATA, Up to 8 external SAS |
| Chipset | Intel 5520 (Dual) |
| Memory | 12 DIMM slots, up to 192 GB (expected availability Q409), 6-channel DDR3 1333 MHz |
| Hard Drives | Up to (5) 3.5-inch 7200 rpm SATA drives: 160, 250, 320, 500 GB, 1, 1.5* TB, 7.5 TB max; Up to (6) 2.5-inch 10K rpm SATA drives: 160, 300 GB SFF, 1.8 TB max; Up to (5) 3.5-inch 15K rpm SAS drives: 146, 300, 450 GB, 2.25 TB max |
| Graphics | Professional 2D: NVIDIA Quadro NVS 295 (256 MB) Entry 3D: NVIDIA Quadro FX 380 (256 MB), ATI FirePro V3700 (256 MB), NVIDIA Quadro FX 580 (512 MB) Midrange 3D: NVIDIA Quadro FX 1800 (768 MB), ATI FirePro V5700 (512 MB) High-end 3D: NVIDIA Quadro FX 3800 (1 GB), ATI FirePro V7750 (1 GB), NVIDIA Quadro FX 4800 (1.5 GB), NVIDIA Quadro CX, NVIDIA Quadro FX 5800 (4 GB) |
| Power Supply | 850-Watt 85% efficient power supply or 1110-Watt 88% efficient |
| Dimensions (H x W x D) | 17.5 x 8.0 x 20.7 in (44.51 x 20.35 x 52.65 cm) |
