PowerEdge R7625
The new Dell PowerEdge R7625 is a 2U, dual-socket rack server. Designed to be the backbone of your data center,
this extremely powerful server provides ample performance and flexible, low-latency storage options in an air or Direct
Liquid Cooled (DLC) configuration.
Stay ahead of the curve
Delivering breakthrough innovation for traditional and emerging workloads, including high performance
compute (HPC), virtual desktop integration (VDI) and virtualization, using the latest performance and density with
optional acceleration.
Extreme performance in a platform that grows with your business
• Using AMD EPYC 4th generation processor to deliver up to 50% more core count per single socket platform in an
innovative air or liquid-cooled chassis.
• Enables DDR5 at 4800 MT/s memory and PCIe Gen5 with double the speed of previous Gen4 for faster access
and transport of data optimizing application output.
• Optional DLC is available to more efficiently cool high-performance processors.
Experience more virtual machine density to support the most demanding applications
• Deliver more virtual machines per physical host using increased core count and higher memory footprint than
previous generations.
• Improve responsiveness or reduce app load time for power users with up to 6x single-wide full-length or
2x double-wide full-length GPUs.
| Feature | Technical Specifications |
| Processor | Up to two AMD EPYC 4th Generation 9004 Series with up to 128 cores per processor |
| Memory |
• 24 DDR5 DIMM slots, supports RDIMM 6 TB max, speeds up to 4800 MT/s
• Supports registered ECC DDR5 DIMMs only
|
| Storage Controllers |
• Internal Controllers (RAID): PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i
• Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs or USB
• External HBA (non-RAID): HBA355e
• Software RAID: S160
|
| Drive Bays | Front bays: • Up to 8 x 3.5-inch SAS/SATA (HDD/SSD) max 160 TB • Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 240 TB • Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.88 TB • Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB • Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.64 TB • Up to 8 x EDSFF E3.S Gen5 NVMe (SSD) max 61.44 TB • Up to 16 x EDSFF E3.S Gen5 NVMe (SSD) max 122.88 TB • Up to 32 x EDSFF E3.S Gen5 NVMe (SSD) max 245.76 TB Rear bays: • Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB • Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB • Up to 4 x E3.S (NVMe Gen5 ) max 30.72 TB |
| Power Supply | • 3200 W Titanium 277 VAC or 336 VDC, hot swap redundant • 2800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant • 2400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant • 1800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant • 1400 W Mixed Mode Platinum 100-240 VAC or 240 HVDC hot swap redundant • 1400 W Mixed Mode Titanium 277 VAC or 336 HVDC hot swap redundant • 1100 W Titanium 100—240 VAC or 240 HVDC, hot swap redundant • 1100 W LVDC -48 — -60 VDC, hot swap redundant • 800 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant |
| Dimensions |
• Height – 86.8 mm (3.41 inches)
• Width – 482 mm (18.97 inches)
• Depth – 772.13 mm (30.39 inches) with bezel
758.29 mm (29.85 inches) without bezel
|
| From Factor | 2U Rack Server |
