G493-ZB4-AAP1 4U GPU Server-Dual AMD EPYC 9005/9004/8 PCIe Gen5 Accelerators/48 DDR5 DIMMs/High Performance Computing AI Training
- Overview
- Related Products
G493-ZB4-AAP1 4U Server
Product Feature
The SP5 socket has reached its pinnacle form with 5th Generation AMD EPYC™ processors. The same successful platform that was shared by AMD EPYC™ 9004 & 8004 series processors is now the same one for AMD EPYC™ 9005 series processors. With up to 192 cores, increased frequencies and cache, this top tier performance platform targets general purpose, cloud native, and technical computing. Building on the advantages of the EPYC™ 9004 series, the new EPYC™ 9005 series adopts the 3nm process with AMD “Zen5” and “Zen5c” core architecture, excelling in both energy efficiency and cost optimization. GIGABYTE has already prepared for this new processor with new servers and updates to existing products for 4th Gen AMD EPYC™ processors.
Specification
| From Factor | 4U |
| CPU |
AMD EPYC 9005 Series Processors Dual processor |
| Memory Slots | 48 x DIMM slots |
| Storage | Front side: 12 x 2.5" Gen5 NVMe/SATA - (4 x NVMe from PEX89144_0, 4 x NVMe from PEX89144_1) - (2 x NVMe from CPU_0, 2 x NVMe from CPU_1) - (SATA from CPU_0) |
| Power Supply | 3+1 3000W 80 PLUS Titanium redundant power supplies |
Dimensions |
447 x 176 x 880 mm |
Contact Us

Package

Certification

Product Display
