R960 Description
Accelerate compute-intensive, high-performance core workloads
The R960 boosts business-critical operations with unprecedented scale-up capabilities in a 4U air-cooled form factor with four (4) Intel Xeon Scalable Processors to empower business and drive data-driven initiatives.
• With a maximum CPU core count of 60 cores and the ability to support 64 DDR5 DIMMs for a total of 16 TB of memory, the R960 is positioned for the largest in-memory databases without the need for slower I/O
database access.
• Scale up business needs with support for up to 24 NVMe drives, DDR5 DIMMs,12 PCIe Gen5 slots for I/O expansion, LOM, and industry standard OCP to enable customers flexible network connectivity.
• Enable fast 1:1 CPU-I/O communications with PCIe Gen5 adaptor support.
Business-critical performance, business-wide
• Harness latest generation technologies to maximize data transformation, support large in-memory databases, and generate faster insights to drive the business forward.
• Leverage new workload accelerators built into each Intel Xeon processor that are purpose-designed for peak performance in traditional and emerging business applications.
• Install up to 4 GPU accelerators to boost AI-based business applications and rapidly transform real-time data and analytics into decision-based outcomes.
• Increase power user and worker productivity with up to 4 VDI accelerators.
Feature | Technical Specifications |
Processor | Up to four 4th Generation Intel Xeon Scalable processor |
Memory |
64 DDR5 DIMM slots, supports RDIMM 16 TB max, speeds up to 4800 MT/s |
Drive Bays |
Front bays: • Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 122.88 TB • Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) max 245.76 TB • Up to 24 x 2.5-inch NVMe (SSD) max 368.64 TB • Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) + 8 x 2.5-inch NVMe (SSD) max 368.64 TB • Up to 32 x 2.5-inch SAS/SATA (HDD/SSD) max 491.52 TB |
Storage Controllers | Internal Controllers: PERC H965i, PERC H755, PERC H355, HBA355i, HBA465ii |
From Factor | 4U rack server |
Power Supply |
• 1100 W Titanium 100—240 VAC or 240 HVDC, hot swap redundant • 1400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant • 1800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant • 2400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant • 2800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant |
Dimensions |
• Height – 174.3 mm (6.86 inches) • Width – 482 mm (18.97 inches) • Depth – 883.195 mm (34.77 inches) with bezel 869.195 mm (34.22 inches) without bezel |
