Gigabyte XL43-ZX0-AAS2 4U Rack Server-Supports 8 PCIe Gen5 GPUs/Dual AMD EPYC 9005 Series/24 DIMM Slots/2 10Gb/s LAN Ports/Visual Computing & AI Inference
Supports up to 8 x Dual slot Gen5 GPUs
Dual AMD EPYC 9005 Series Processors
12-Channel DDR5 RDIMM, 24 x DIMMs
2 x 10Gb/s LAN ports via Intel X710-AT2
4 x 2.5" Gen5 NVMe hot-swap bays
2 x M.2 slots with PCIe Gen3 x2 and x1 interface
8 x FHFL PCIe Gen5 x16 slots for GPUs
1 x FHFL PCIe Gen5 x16 slot
4 x 3200W 80 PLUS Titanium redundant power supplies
- Overview
- Related Products
XL43-ZX0-AAS2 4U Server
Product Feature
The SP5 socket has reached its pinnacle form with 5th Generation AMD EPYC™ processors. The same successful platform that was shared by AMD EPYC™ 9004 & 8004 series processors is now the same one for AMD EPYC™ 9005 series processors. With up to 192 cores, increased frequencies and cache, this top tier performance platform targets general purpose, cloud native, and technical computing. Building on the advantages of the EPYC™ 9004 series, the new EPYC™ 9005 series adopts the 3nm process with AMD “Zen5” and “Zen5c” core architecture, excelling in both energy efficiency and cost optimization. GIGABYTE has already prepared for this new processor with new servers and updates to existing products for 4th Gen AMD EPYC™ processors.
Specification
| From Factor | 4U |
| CPU |
AMD EPYC™ 9005 Series Processors Dual processor |
| Memory Slots | 24 x DIMM slots |
| Storage |
Front hot-swap: Internal M.2 (I/O board): |
| Power Supply | 4 x 3200W 80 PLUS Titanium redundant power supply |
Dimensions |
438 x 176.6 x 802.5 mm |
